QOB220VH - Square D 20 Amp 2 Pole Bolt-On Breaker

0 reviews Write a review

Brand:	Schneider Electric
Product Code:	QOB220VH

Product available in stock : 1000

$87.06

Qty

Free Shipping Policy

FREE Shipping on orders over $49.

3bbreaker.com offers one to five day delivery. The variation depends on the warehouse location for the product(s).

1-Year Warranty

All products carry a 1-year warranty from 3bbreaker.com. All of our breakers are authentic and factory new.

Returns are Easy

You may return items within 30 days of delivery for a refund.

Next Day Shipping

We strive to ship out your items within one business day.

In rare circumstances, 3bbreaker.com may reserve up to 5 business days to complete shipment. Feel free to contact us if your order is time sensitive.

QOB220VH - Square D Bolt-On 20 Amp Breaker

Square D QOB series molded case circuit breaker double pole single phase ampere rating 20-amps voltage rating 240v with standard interrupting rating of 22 kiloampere bolt-on mounting used on nq panelboards.

Specifications:

Product: Miniature circuit-breaker

Range: QO

Line Rated Current: 20 A

System Voltage: 120/240 V AC, 240 V AC

Mounting Type: Bolt-on

Number of Poles: 2P

Circuit Breaker Type: Standard

Ratings: HACR rated

Electrical Connection: Pressure plate

Inturrupt Rating: 22 kA at: 120/240 V AC 50/60 Hz, 22 kA at: 240 V AC 50/60 Hz, 22 kA at: 120 V AC 50/60 Hz

Number of Panel Spaces: 2

Wire Size: AWG 14...AWG 8 (copper or aluminium)

Height: 3 in

Depth: 2.91 in

Width: 1.5 in

Certifications: CSA, UL listed

Ambient Rating: 104 Degree F (40 Degree C)

Authentic Square D Product

Dimensions (H x W x L): 3" x 1.5" x 2.91"

Alt model: q0b220vh
